Network Commands
Router (IP)
DS2000-TS Administrator’s Guide
B - 21
B.2.8 TCP Multicast
The DS2000-TS supports a broadcast feature that lets the user configure TCP multicast groups. A maximum
of 50 TCP sources can be defined, which can connect to a maximum of 60 destinations. Traffic received on
the source IP address and socket is sent to each of the destinations; any traffic received on the destinations is
sent only to the source. When a user connects to the source IP address and socket, TCP connections are
automatically launched to the destinations. If a destination is cleared, the DS2000-TS attempts to reestablish
the connection every 10 seconds. If the source is cleared, all destinations are cleared.
The source must be configured first; this is done by defining a Multicast async service type. The destinations
are configured from the Multicast Destinations screen, which is found under <2> Network, <1> Router,
<10> TCP Multicast. The Multicast Destinations screen is shown in Figure B-19.
Table B-4. Phase 1 and Phase 2 Stat es
State Description
Phase 1 States
VPN IDLE No setup attempt is pending (not normally seen)
PRE-SETUP Waiting for timeout to initiate setup
AGGR INIT Initiated aggressive mode setup
AGGR RESP Aggressive mode response sent
MAIN SA IN Main mode security association initiated
INIT RX Main mode setup message received
MAIN SA RE Main mode security association response sent
MAIN KEY IN Main mode key setup set
MAIN KEY WT Waiting for key response (this can take seconds depending
on the processor speed at the other end)
MAIN KEY RE Main mode key response sent
MAIN ID IN Main mode ID message sent
MAIN ID RE Main mode ID response sent
CONNECTED Phase 1 setup is complete
Phase 2 States
QK SETUP IN Phase 2 setup (quick mode) initiated
QK SETUP WT Waiting for phase 2 response (can take seconds depending
on the processor speed at the other end)
QK SETUP RE Phase 2 response sent
NEW GRP IN New group request initiated
VPN UP VPN is up and sending data
