Toggle the Action column settings for the protocols shown, as desired.
•
The Def protocol entry refers to the default action for all frames not meeting any of the other filter
definitions (i.e., either do not appear in the table or cannot be derived from masks that appear in the
table). The default setting is Forward
.
When all of entries are complete, enter <Y> in the Process selections field and press <Enter>. You will be
returned to the Router Setup and Status menu.
Redisplay the IP Filter Table by selecting the IP Filter option to verify the desired actions.
The IP Filter Table will have been resorted by class and address according to the following sorting rules:
1. Entries with specific addresses appear before entries with masks.
2. Addresses and masks are sorted from low to high values.
3. Actions are sorted (in order of decreasing priority) by class as follows:
a.
BOTH (source and destination address)
b.
SOURCE (source address only)
c.
DESTINATION (destination address only)
d.
NETBOTH (both source and destination network masks)
e.
NETSOURCE (source network mask only)
f.
NETDESTINATION (destination network mask only)
In the sorted table, an address or mask of *.*.*.* indicates “Don’t care” and is not used for filtering.
Figure B-8. UDP/TCP Filter Table Menu
*** UDP/TCP Filter Table ***
Last changed: 7-14-04 12:33:29
Protocol Socket Name Action
(Toggle) (Toggle)
1 Def Forward
__________[DynaStar_24]___________ Process selections (Y/N): Y
Use <TAB> and CURSOR to move fields Press ESC to return to previous menu
