Figure A-12. Statistics For Console Port Menu
Table A-8. Console Port Statistics Attributes
Field Description
Port Number The number of the port whose statistics are being displayed.
Enabled Date and time the port was enabled.
Cleared Displays date and time when statistics were last cleared using the <CTRL-D> option.
Current Status Indicated whether a connection is Up or Down. Also may show the Packet and Cell
states for diagnostic purposes and will display Disabled if port is disabled.
Connection Type Fixed DTE for Console port
Flow Control Status Indicated whether flow control has been received (Yes /No) or sent (Yes/No) and shows
the number of characters discarded after flow control is sent. Flow control can be XON/
XOFF or data set signals.
Incoming Signals Status (On/Off) of incoming data set signals.
Characters The number of asynchronous characters sent/received.
Breaks The number of line breaks received.
Call Attempts
Succeeded
Failed
The total number of call attempts, to and from, followed by the number of calls
successfully received (Succeeded) and Failed.
Parity errors The number of parity errors (line errors).
Framing errors The number of incorrect stop bits on asynchronous characters (line errors).
Statistics for console port CON: Console Enabled: 2-12-05 12:08:06
Cleared: 2-15-05 8:10:04
Current status: Up (Ps 3 Cs 2) Connection type: DTE
Flow control status: Incoming signals:
Received = No CD = On
Sent = No CTS = On
Character discard = 0
To device From device
Characters 104368 109 Parity errors = 0
Breaks 0 Framing errors = 0
Call attempts 0 2 Overruns = 0
Succeeded 0 2 Unable to store character = 0
Failed 0 0
Current connection information: To port From port
LCN = 1 Data packets 247 41
from = Data segments 422 41
port = CON Data characters 23119 70
to = 9999 Interrupt packets
port = VRT Reset packets 0 0
Duration = 0:54:38
________[DynaStar_b441334]________ Press <RET> for statistics update
Press ESC to return to previous menu Press <CTRL-D> to clear statistics
