Figure A-15. Port Monitor Menu
Table A-9. Port Monitor Parameters
Parameter Definition Default Range
Display Indicates the type of display desired. Link/All Link/All
Packet
IP
IP-FULL
TCP
Format Indicates how the data will be displayed. Hex Hex
ASCII
Number of lines Sets the maximum number of lines to display. 5 0 (unlimited)
1-10
Time stamps Indicates whether or not to use timestamps and, if
used, the type to use.
None None
Relative
Differential
Frame Numbering For X.25 only, indicates whether to use frame
numbering
NN/Y
Packet Types Indicates the type of packets to display. Data Only All Frames
Data Only
Control
Start Channel/
End Channel
Indicates the range of data to display (specified by
the DLCI or LCN).
N/A DLCI or LCN
number
Filter on Specifies the type of traffic, if any, on which to filter. Both Both
None
Transmitted
Received
*** Port Monitor CON ***
Display Packet
Format Hex
Number of lines 5 (0 = unlimited, 1-10)
Time Stamps None
Frame Numbering N
Filter on None
Mac Address (Ctrl-D to clear)
IP Address 0.0.0.0 (Ctrl-D to clear)
TCP Socket 0 (0-65535)
_________[DynaStar_6b2c]__________ Process selections (Y/N): Y
<RET> to toggle or type value Press ESC to return to previous menu
Cursor up/down for more entries Use <CTRL-D> to delete entry
