Table 5-3. Printer Troubleshooting (Cont'd)

Fault Probable Cause Checks Corrective Action

No communication to Printer (Continued)

Incorrect Address

settings

Check printer address

jumpers (no Jumper

means address is 70HEX)

Set the correct Hex address

in SiteOmat

Faulty Printer Replace Printer

Paper is not automatically cut

Paper is not being

cut at the end of

the printing

Incorrect SiteOmat

setting

Check SiteOmat printing

settings

Set SiteOmat printing

settings accordingly

Faulty Printer cutter Replace Printer cutter

Faulty Printer Replace Printer

Islander PLUS Manual

107
