4-5. INDICATORS
The printer module includes a buzzer to provide audio display on the following events:
• Printing is in progress
• Paper alerts – paper run out or approximately 25% left (see paragraph 4-8.1)
• Receipt ready
The printer also includes LEDs (see Figure 4-3) in its front panel for communication monitoring.
At turn on, the LEDs and the buzzer are activated for a short period of time.
4-6. SPECIFICATIONS
This section lists the physical, electrical and environmental specifications of the printer, as follows:
Supply Voltage: 24 - 26 VDC
Power Consumption: Standby 15 W
Typical 60 W
Communication Interface: RS-485 – 9600 bps Half-Duplex
Paper Type: Thermal, 57 mm (W), 55 gr., 101 mm diameter
Paper Maximum Printing
Area Width:
54 mm
Maximum Printing Speed: 120 mm/sec.
Autocutter: Integrated
Islander PLUS Manual
85
