1-8. SPECIFICATIONS
The following physical, electrical and environmental specifications are applicable to the Islander
PLUS:
Islander PLUS - Pedestal with up to 4
mechanical pumps
Islander PLUS - Pedestal with up to 8
mechanical pumps
Name Islander PLUS Islander PLUS
Supply voltage: 100 – 240 VAC 120 / 240 VAC
Power consumption: 2A max. 2A - 1A max. (Accordingly)
Operating temperature:
-22 °F to +113 °F (-30°C to +45 °C)
-4 °F to +113 °F F (-20°C to +45 °C)
(Option with printer)
-40 °F to +104 °F (-40°C to +40 °C)
-4 °F to +104 °F (-20°C to +40 °C)
(Option with printer)
Storage temperature: -40 °F to +158 °F (-40°C to +70 °C)
-40 °F to +158 °F (-40°C to +70 °C)
Humidity: 80% Non-condensing 80% Non-condensing
Dimensions:
W x H x D: 9.45 x 61.02 x 9.45 " (24 x
155 x24 cm)
W x H x D: 9.45 x 61.02 x 9.45 " (24 x
155 x24 cm)
Communication
interface:
RS-485 – 9600 bps, Half-Duplex
RS-232
Ethernet RJ-45 - 10 Mbps
EIA 802.15.4
RS-485 – 9600 bps, Half-Duplex
RS-232
Ethernet RJ-45 - 10 Mbps
EIA 802.15.4
Pump Control Maximum
Current
(4 Solid State Relay
Channels):
Motor maximum: 1 HP at 115 VAC or
2 HP at 230 VAC. Additional external
relay must be used if pump motor
exceeds these limitations.
Motor maximum: 3/4 HP at 115 VAC
or 1.5 HP at 230 VAC. Additional
external relay must be used if pump
motor exceeds these limitations.
Power supply output
voltage to Pulsar unit
Power supply maximum
output current
12 VDC +/- 20%
80 mA max
12 VDC +/- 20%
30 mA max
Pulsar Input High level
voltage
Pulsar Input High level
sink current (@15V)
9 to 15 VDC
3 mA
9 to 15 VDC
3 mA
In use "On" level (Input) 100 – 240 VAC, 50/60 Hz, 2 W (20
mA)
100 – 240 VAC, 50/60 Hz, 2 W (20
mA)
In use "Off" level (Input)
0 to 20 VAC
0 to 20 VAC
