3-4. MAPPING THE SITE– EXAMPLE
3-4.1. General
This paragraph shows an example of the mapping of a site. This procedure consists of the
following steps:
• Locating and mapping all objects of the site
• Assigning logical identifications (Id.) to the devices
• Assigning the Ethernet and Serial addresses of devices linked to the network
• Obtaining a functional and physical map of the devices in the site.
3-4.2. Locating all objects of the site
• Locate the roads around the site
• Locate the islands and their dispensers
• Locate the fuel tanks
• Locate the intended position of the Islander PLUS pole
• Locate the intended position of each ICR PLUS
• Draw a basic map of the site with all the objects
3-4.3. Assigning Logical IDs
3-4.3.1. To each fuel tank
• Assign the tank sequential number (coordinated with the station manager)
• Assign its fuel code and name
• Assign its TLG Probe (AP) Id.
3-4.3.2. To each Dispenser Unit
• Assign an id. to every dispenser name and Pump Server
• Assign an id. to every dispenser pump (P)
• Assign an id. to every pump CPU addresses if any
• Assign an id. to its nozzles (N)
• Assign to each nozzle the tank (T) Id. to whom it is linked.
3-4.3.3. In the Islander PLUS pole
• Assign the Islander PLUS its id.
• Assign the panel printer (PP) its Id.
• Assign their ids in an ascending order with the dispenser unit ids
3-4.4. Mapping
• Draw a map of the site.
• Use the map methodology and Ids. for later setup configuration.
