Gasboy Islander PLUS - 3-9.2. Tokheim Electronic Pump; Wiring Connections

Table 3-2. Islander PLUS Terminal Block -4 Mechanical Pump – Connections Definition
Terminal No.
Signal Name
Functional Description
3 RX-RS232 Receive Data interface
4 RS-485 GND Data link to Density Probes Console Box /
5 RS-485_+ Density Display
6 RS-485_- Chassis / Positive / Negative connections
7 PULSER_1 Pulser Input – Nozzle 1
8
PULSER_2
Pulser Input – Nozzle 2
9 PULSER_3 Pulser Input – Nozzle 3
10 PULSER_4 Pulser Input – Nozzle 4
11 GND_1_P Nozzle Grounding – Nozzle 1
12 GND_2_P Nozzle Grounding – Nozzle 2
13
GND_3_P
Nozzle Grounding – Nozzle 3
14 GND_4_P Nozzle Grounding – Nozzle 4
15 +12V_1_P +12 VDC Output to Pulser – Nozzle 1
16 +12V_2_P +12 VDC Output to Pulser – Nozzle 2
17 +12V_3_P +12 VDC Output to Pulser – Nozzle 3
18
+12V_4_P
+12 VDC Output to Pulser – Nozzle 4
19 IN USE 1 A Handle Up - In Use signal input - Nozzle 1
20 IN USE 2 A Handle Up - In Use signal input - Nozzle 2
21 IN USE 3 A Handle Up - In Use signal input - Nozzle 3
22 IN USE 4 A Handle Up - In Use signal input - Nozzle 4
23
IN USE 1 B(-)
Handle Up – AC In Use signal return - Nozzle 1
24 IN USE 2 B(-) Handle Up – AC In Use signal return - Nozzle 2
25 IN USE 3 B(-) Handle Up – AC In Use signal return - Nozzle 3
26 IN USE 4 B(-) Handle Up – AC In Use signal return - Nozzle 4
27 LINE 1 Pump control 220/110 VAC Input - Nozzle 1
28
LINE 2
Pump control 220/110 VAC Input - Nozzle 2
29 LINE 3 Pump control 220/110 VAC Input - Nozzle 3
30 LINE 4 Pump control 220/110 VAC Input - Nozzle 4
31 LOAD 1 Pump control output - Nozzle 1
32 LOAD 2 Pump control output - Nozzle 2
33
LOAD 3
Pump control output - Nozzle 3
34 LOAD 4 Pump control output - Nozzle 4
35 LINE IN (115/230v) Line Connection, Islander PLUS power input
36 NEUTRAL IN (115/230v) Neutral Connection, Islander PLUS power input
Islander PLUS Manual
60
