Gasboy Islander PLUS User Manual

Terminal No.
Signal Name
Functional Description
22 +12V_6_P +12 VDC Output to Pulser – Nozzle 6
23 +12V_7_P +12 VDC Output to Pulser – Nozzle 7
24 +12V_8_P +12 VDC Output to Pulser – Nozzle 8
25
IN USE 1 A
Handle Up – AC In Use signal input - Nozzle 1
26
IN USE 2 A
Handle Up – AC In Use signal input - Nozzle 2
27 IN USE 3 A Handle Up – AC In Use signal input - Nozzle 3
28 IN USE 4 A Handle Up – AC In Use signal input - Nozzle 4
29 IN USE 5 A Handle Up – AC In Use signal input - Nozzle 5
30 IN USE 6 A Handle Up – AC In Use signal input - Nozzle 6
31 IN USE 7 A Handle Up – AC In Use signal input - Nozzle 7
32
IN USE 8 A
Handle Up – AC In Use signal input - Nozzle 8
33 IN USE 1 B(-) Handle Up – AC In Use signal Return - Nozzle 1
34 IN USE 2 B(-) Handle Up – AC In Use signal Return - Nozzle 2
35 IN USE 3 B(-) Handle Up – AC In Use signal Return - Nozzle 3
36 IN USE 4 B(-) Handle Up – AC In Use signal Return - Nozzle 4
37 IN USE 5 B(-) Handle Up – AC In Use signal Return - Nozzle 5
38
IN USE 6 B(-)
Handle Up – AC In Use signal Return - Nozzle 6
39
IN USE 7 B(-)
Handle Up – AC In Use signal Return - Nozzle 7
40 IN USE 8 B(-) Handle Up – AC In Use signal Return - Nozzle 8
41 LINE 1 Pump control 220/110 VAC Input - Nozzle 1
42 LINE 2 Pump control 220/110 VAC Input - Nozzle 2
43 LINE 3 Pump control 220/110 VAC Input - Nozzle 3
44 LINE 4 Pump control 220/110 VAC Input - Nozzle 4
45
LINE 5
Pump control 220/110 VAC Input - Nozzle 5
46 LINE 6 Pump control 220/110 VAC Input - Nozzle 6
47 LINE 7 Pump control 220/110 VAC Input - Nozzle 7
48 LINE 8 Pump control 220/110 VAC Input - Nozzle 8
57 NEUTRAL IN (115/230v) Neutral Connection, OrIC power input
58 LINE IN (115/230v) Line Connection, OrIC power input
59
GROUND IN
Ground Connection, OrIC power input
9
PULSER_1
Pulser Input – Nozzle 1
Islander PLUS Manual
62
