86 Reference Data
System specifications
The following specifications reflect the basic capabilities of the computer. Your
computer may contain optional equipment that uses some of the resources
described below or which provides additional resources. All specifications are
subject to change.
Mechanical specifications
The computer conforms to the following mechanical specifications:
Processor One Celeron™ or Pentium™ III processor with 66, 100, or
133 MHz front side bus.
Chipset Intel 810e chipset
RAM capacity Two DIMM sockets on the system board support Synchronous
Dynamic Random Access Memory (SDRAM) DIMMs. Maximum
memory is 512 MB.
BIOS Flash BIOS for easy updates from diskette.
IDE interfaces Supports as many as four ATAPI/IDE devices (hard drives, CD
drives, LS-120 drives) using two onboard PCI IDE adapters. (The
chassis provides space for as many as three ATAPI/IDE devices
and a diskette drive.)
Diskette drive Diskette controller integrated on the system board.
I/O ports One parallel port, one serial port, two USB ports, one video port,
one LAN port, one microphone-in port, one audio-out port, one
PS/2 keyboard port, and one PS/2 mouse port. The parallel and
serial ports are configurable through System Setup. No jumper
settings are required.
Expansion Slots Two low-profile, half-length PCI slots.
Power Supply 110 watts. ATX power connector for easy power cable
changeover.
Certification FCC Class B, DOC, VCCI, C-Tick, UL, CUL, CB Scheme.
Mini Desktop case size 3.95 in. (100 mm) x 13.25 in. (336 mm) x 15.25 in. (387 mm)
(H x W x D).
Weight 20.0 lbs (9.1 kg) SE/XL
Monitor supported Max weight 75 pounds
8506999.book Page 86 Friday, December 15, 2000 8:22 AM
