Instructions for SL500DC/SL800DC
www.gatexpertstore.com
Installation
Before You Start
· SL500DC/SL800DC Sliding Gate Automation Kit is suitable for powering the opening and
closing motion of gates up to 500, 800kg in weight, up to a length of 12m.
· Gate motion is achieved by the rotating output gear of the gate opener driving the gear rack
(sold separately) fitted to the moving gate.
· The gate opener requires you to press the remote control once to open, and once again to
close. This is a safety feature to ensure safe operation.
· The opener must be fitted within private property, never externally to a property’s boundary.
Any works done to the gate opener must be completed whilst the power is off and the opener is
unplugged. Any modifications/alterations/works to AC power components must only be completed by
a licensed electrician
Tools Required
· Tape measure
· Level
· 12mm concrete drill and hammer (when uses expansion screws)
· Phillips head screwdriver
· Straight screwdriver
Example Sliding Gate
Gate Track and Track Wheels Gate End Catch Gate Guide Rollers Gate Stop
Figure 4
Please ensure that the gate opener power cable is not plugged in at any stage before Step 8.
