GATEXPERT SL500DC - Opening Direction Setting (L4)

Instructions for SL500DC/SL800DC
www.gatexpertstore.com
39
L1
L2
L3
L4 L5
Cancel start-up delay function
Delay for 0.5 sec
Delay for 1 sec
Delay for 1.5 sec
L1
L2
L3
L4 L5
L1
L2
L3
L4 L5
L1
L2
L3
L4 L5
Indicator light status：
Off
On
Flicker
Status Instruction
Table 2 Start-up Delay Time
Opening Direction Setting (L4)
This setting is for users to change the gate opening direction without exchanging the motor
wires, but have to note the limit stop position.
A. Operation Instruction:
1. Press and hold “PROG” button for 3 sec. to enter into basic menu.  Indicator light L0
will flicker once, then L1 will be steady on.
2. Press “PROG” button again for 3 sec. to enter into advanced menu.  L0 will flicker
twice, then L1 will be steady on.
3. Press “+” button three times to select opening direction option.  Indicator light L4 will
be steady on.
4. Press “SET” button once to enter into opening direction setting.  Indicator light L1 will
indicate the current setting. (Default is L1 on)
5. Press “+” or “-” button to set the opening direction.  Indicator light L1 on or off stands
for the 2 directions. (L1 on: open to right-hand; L1 off: open to left-hand)
Press “SET” button once to save and system will automatically exit.  The indicator
lights L1-L5 will be on in sequence, then all will flicker once and off.
