Puma III User Manual
Operation 4-4
Option B
Insert the two roll holders into the roll media support set, and then place the roll media
directly between the two roll holders. (Figure 4-7)
Step 3
Load the media on the platen. After loading the roll media, flatten the media on the platen
and hold the front edge of the roll media firmly (Figure 4-8)
Figure 4-7
Figure 4-8
