RX Series User Manual
General Information 1-5
1.4.3 The Whole View of RX Series (Figure 1-3)
Figure 1-3
Roll Holder – holds
and supplies the roll
media for cutting.
Roll Holder Guide
Bushes – serve to
keep the roll media in
place when media is
pulled from the roll.
T-Stand – supports
the cutting plotter
Stand Beam –
stabilizes the body.
Roll Holder
Support – supports
roll holders.
T-Stand – supports
the cutting plotter
