RX Series User Manual
Operation
4-3
Note:
Please pull up the bottom of all pinch rollers (Figure 4-5) before the lever is pushed
backwards to ensure accurate media width detection.
4.1.2 Loading the Roll Media
Step 1
Put the roll holder guide bushes on two roll holders (Figure 4-6).
Figure 4-6
ENABLE
Pull up bottom to release grip
Figure 4-5
