RX Series User Manual
The Control Panel 3-7
3.4 Menu Items
Below describes the functions of menu items
Menu or Key
Function Setting Default
--- Media sizing ---
Roll To measure media width. Maximum Media
Length 150M
Edge To measure media width and pull the media back till
the front
paper sensor open.
Maximum Media
Length 150M
Single To measure media width and length. Maximum Media
Length 10M
--- POWER ---
To indicate the power status.
[ Arrow Keys ]
1. To move the tool carriage position on X or Y axis.
2. To select functions or change values of settings.
[ ENTER ]
1. The displayed parameters will be saved automatically.
2. To set a new origin at the present tool carriage position.
In “offline” mode, moving the tool carriage to desired
position by [Arrow Keys], then press [ENTER] key to set a
new origin. While moving with the parameters of XY-axes
displayed, press [MISC] key will enable fine-tune
movement; press [MISC] key again to disable the function.
[ PAUSE/RESUME ]
To temporarily halt the cutting process.
To resume the process by press [Pause/Resume] key again.
[ ONLINE/OFFLINE ]
1. To switch between online mode and offline mode.
2. To stop the cutting job or abort the change of setting.
Once press this key, the cutting job will be terminated
immediately and cannot be resumed.
[ OFFSET ]
To set or modify the distance between the blade tip and the
center axis. T
hrough left or right arrow keys, users can select
the blade used (Red, Green, Yellow, Blue, Black capped
blade or Pen) then adjust the offset values after pressing
Enter if necessary
0.000~1.000mm
0.275mm
[ FORCE ]
To set or modify the value of tool force.
When the cutting force exceeds 450g, the maximum cutting
speed would be 30cm/sec and the cutting quality would be
Small Letter Mode and while the cutting force is 300g-449g,
the maximum cutting speed would be 30 cm/sec and the
cutting quality would be Fine Mode.
5~600gram;
5 gram/per step
80 gram
[ SPEED ]
Speed To set or modify tool speed at horizontal moving.
When the cutting speed exceeds 72 cm/sec, the cutting
quality would be Normal Mode.
3~153cm/sec;
3cm/sec per step
72cm/sec
Up Speed To set or modify tool speed at vertical moving. 3~153cm/sec;
3cm/sec per step
72cm/sec
