1.1 Introduction
RX series cutting plotters have been designed to produce computer-generated images or
perform contour cutting on sheets or rolls of vinyl media.
This manual covers the following models of RX series cutting plotters:
‧RX-61 for media width: 50mm(1.97”) ~ 810mm(31.88”)
‧RX -101S for media width: 50mm(1.97”) ~ 1326mm(52.2”)
‧RX -132S for media width: 50mm(1.97”) ~ 1635mm(64.37”)
‧RX -183S for media width: 50mm(1.97”) ~ 2145mm(84.44”)
1.2 Package Items
The package of the RX series contents the items listed below, please check carefully.
If you find any item missing, please consult your local dealer for further assistance.
S
S
t
t
a
a
n
n
d
d
a
a
r
r
d
d
I
I
t
t
e
e
m
m
Q
Q
u
u
a
a
n
n
t
t
i
i
t
t
y
y
1. Cutting Plotter 1
2. Stand Set ( for RX-101S/132S/183S only )(Optional for RX-61)
 2 piece of T-shape stand
 1 piece of stand beam
 18 pieces of M6 screws
 1 piece of M5 L-shape hexagon screw driver
 1 piece of Installation Guide for Stand Set
1
3. Flexible Media Support System Package
Items
183S/132S/101S
61
1 set of Roll Media Flange (2 pieces)
V V
1 set of Roll Holder (2 pieces)
V V
1 set of Roll Holder Guide Bushes (4 pieces)
V V
1 set of Roll Holder Support (2 pieces)
V V
1 piece of M6 L-shape hexagon screw driver
V V
1 piece of Installation Guide for Roll Holder
V
1 piece of M5 L-shape hexagon screw driver
V
1 set of Desktop Support Brackets (2 pieces)
V
4 pieces of Plastic Foot
V
4 pieces of M4 screws
V
12 pieces of M6 screws
V
1 piece of M4 L-shape hexagon screw driver
V
1
