RX series Specification A-1
Model Number RX-61 RX-101S RX-132S RX-183S
Operational Method Roller-Type
Max. Cutting Width 610mm (24in) 1010mm (40in) 1320mm (52in) 1830mm(72in)
Max. Cutting Length 50m (164ft)
Max. Media Loading Width 810mm(31.88in) 1326mm(52.2”) 1635mm(64.37”) 2145mm(84.44”)
Min. Media Loading Width 50mm (1.97in)
Number of Pinch Rollers 2 3 4 5
Acceptable Material Thickness
0.8mm (0.03in)
Drive Motor DC Servo Control
Cutting Force 5~600 g
Max. Cutting Speed 1530 mm/sec (60ips / Diagonal)
Acceleration 4.2 G (gravity)
Offset 0~1.0 mm (with an increase of 0.025mm)
Memory Buffer 16 MB
Interfaces USB 2.0 (Full Speed) and Serial (RS-232)
Type of Command HP-GL, HP-GL/2
Mechanical Resolution 0.006 mm
Software Resolution 0.025 mm
Distance Accuracy ±0.254 mm or ±0.1% of move, whichever is greater
Repeatability ±0.1mm
Automatic-Aligning System
Completely Automatic Contour Cutting System for print to cut solution
Curve & Arc Smoothing Yes
Configurable Origin Yes
Test Cut capability Yes
Tangential mode Yes
Over Cut Yes
Repeat Yes
Copy Yes
Pouncing Yes
Control Panel
LCD (20 digits x 2 lines), 15 Keys, 1 Power LED, 1 Green LED
Power Supply 100 ~ 240VAC 50/60Hz (auto switching)
Power Consumption 251.8watts
Dimension (HxWxD) mm
274.2 * 1098 * 273.5
1149 * 1614 * 606
1149 * 1923 * 606
1149 * 2433 *
760
(HxWxD) in 10.8 * 43.2 * 10.8 45.24 * 63.5 * 23.8 45.24 * 75.7 * 23.8
45.24 * 95.8 *
29.9
Net Weight 25kg 61.8kg 71.5kg 87.2kg
Auto Cut Off Standard
Max. Cut Off Width 696mm 1107mm 1417mm 1927mm
Stand Optional Standard
Media Basket Optional
Temperature 15°C~30°C / 60°F~86°F Operation
Environment
Humidity 25% ~ 75%
 Compatible with Windows 2000/ XP/ Vista/ 7/ 8 and MAC OS X 10.4-10.7
