RX Series User Manual
Table of Contents
5. Automatic-Aligning System
5.1 Introduction 5-1
5.2 Calibrating the System
5.2.1 Media Calibration 5-2
5.2.2 AAS Calibration 5-2
5.2.3 AAS II on RX series 5-3
5.3 Printer Test 5-4
5.4 Registration Mark Offset Range
5.5 Contour Cutting
5-6
5-6
5.6 Tips for AAS 5-8
6. Maintenance
6.1 Cleaning the cutting Plotter 6-1
6.2 Cleaning the Grid Drum 6-2
6.3 Cleaning the Pinch Rollers 6-2
7. Trouble Shooting
7.1 Non-Operational Problems 7-1
7.2 Operational Problems 7-2
7.3 Communication Problems 7-3
7.4 Software Problems 7-4
7.5 Cutting Quality Problem 7-5
7.6 USB connection Problems 7-6
Appendix
A-1
RX series Specification A-1
A-2
Blade Specification A-2
A-3 CorelDRAW Plug-In Instruction A-3
A-4 SignPal 10.5 Instruction A-4
A-5 GreatCut Instruction A-5
A-
6
Illustrator Instruction
A-6
A-
7
DirectCut A-7
