Step 2
-- Option A (Use the media flanges) (Recommended)
Insert a roll media flange at the end of each roll media and tighten the thumbscrew until the
roll media is firmly gripped (see Figure 4-7).
Then put the roll media on the roll holders. Adjust the position of the roll media ensure that
media flanges are able to run in the grooves of roll holder guide bushes (Figure 4-8)
-- Option B
Insert the two roll holders into the roll media support set then place the roll media
directly between the two roll holders (
Figure 4-9
).
Figure 4-9
