A1 STATUS CHAPTER 4: ACTUAL VALUES
Output relays summary
PATH: ACTUAL VALUES > A1 STATUS > OUT RELAYS SUMMARY
OUTPUT RELAYS SUMMARY
This display shows a summary of the states of all output relays.
NOTE
NOTE:
Output relay #7 is the Critical Failure relay, used to indicate the correct functioning of the
339 relay. This output relay shows the status "ON" when the 339 relay is powered up and
set to "Ready" and no self-test alarms are active, under
SETPOINTS > S1 RELAY SETUP > S1
INSTALLATION > RELAY STATUS.
Logic elements summary
PATH: ACTUAL VALUES > A1 STATUS > LOGIC ELEM SUMMARY
LOGIC ELEM SUMMARY
This display shows a summary of the states of all logic elements.
GOOSE status
PATH: ACTUAL VALUES > A1 STATUS > GOOSE STATUS
GOOSE 1 TO 8 STATUS
Range: OFF, ON
Default: OFF
GOOSE HDR status
PATH: ACTUAL VALUES > A1 STATUS > GOOSE HDR STATUS
GOOSE 1 TO 8 H.STATUS
Range: OFF, ON
Default: OFF
61850 status
PATH: ACTUAL VALUES > A1 STATUS > 61850 STATUS
RLY #1 OFF RLY#5 OFF
RLY #2 OFF RLY#6 OFF
RLY#3 OFF RLY#7 ON
RLY#4 OFF
LE#1 OFF LE#9 OFF
LE#2 OFF LE#10 OFF
LE#3 OFF LE#11 OFF
LE#4 OFF LE#12 OFF
LE#5 OFF LE#13 OFF
LE#6 OFF LE#14 OFF
LE#7 OFF LE#15 OFF
LE#8 OFF LE#16 OFF
