GE 339

CHAPTER 6: SETPOINTS S1 RELAY SETUP
339 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 6–13
IEC 60870-5-103 serial
communication
Figure 6-6: IEC 60870-5-103 serial communications settings
PATH:
SETPOINTS > S1 RELAY SETUP > COMMUNICATIONS > IEC61870-5-103
Please refer to the 3 Series Communications Guide for details on how to set up the IEC
60870-5-103 serial communications protocol.
For a complete list of Binary inputs, see Format Code FC134B in the 3 Series
Communications Guide. Note that the format codes differ for each relay model.
IEC60870-5-104
protocol
Figure 6-7: IEC 60870-5-104 protocol settings
PATH:
SETPOINTS > S1 RELAY SETUP > COMMUNICATIONS > IEC61870-5-104
Please refer to the 3 Series Communications Guide for details on how to set up the
IEC 60870-5-104 protocol.
For a complete list of Binary inputs, see Format Code FC134B in the 3 Series
Communications Guide. Note that the format codes differ for each relay model.
DNP communication Figure 6-8: DNP communication settings
PATH:
SETPOINTS > RELAY SETUP > COMMUNICATIONS > DNP PROTOCOL > DNP GENERAL
Please refer to the 3 Series Communications Guide for details on how to set up the DNP
protocol.
For a complete list of Binary inputs, see Format Code FC134B in the 3 Series
Communications Guide. Note that the format codes differ for each relay model.
