339 order codes
The information to specify a 339 relay is provided in the following order code table.
Figure 1-3: Order Codes
NOTE
NOTE:
Features related to each order number are subject to change without notice.
Empty chassis
The 339 protection relay chassis used with a drawout relay is available separately, for use
as a partial replacement or in test environments. Many features are supported by the
cards and ports within the chassis, as is reflected in the chassis order code.
896800A7.fm
339  * * * * * S N * * * * *
Interface 339
|
| | | | | | | | | | 339 Motor Protection System
User
Interface
E
||||| ||||| English without programmable LEDs
L
||||| ||||| English with programmable LEDs
Phase Currents
a
a. Phase current option P0 and Ground current option G0 is only available on the non-drawout version
(Case Design option N)
P0 | | | | | | | | | 1 A and 5 A configurable phase current inputs
P1 | | | | | | | | | 1 A 3-phase current inputs
P5 | | | | | | | | | 5 A 3-phase current inputs
Ground Currents
b
b. Ground current options G0/G1/G5 must match the corresponding P0/P1/P5 Phase currents
G0||| ||||| 1 A and 5 A configurable ground current input
G1||| ||||| 1 A ground current input
G5||| ||||| 5 A ground current input
Power Supply L | | | | | | | 24 to 48 V DC
H | | | | | | | 110 to 250 V DC/110 to 230 V AC
Input/Output
c
c. The Input/Output option R is only available on the drawout version (Case Design option D). The 339 does not support both
internal RTDs and RMIO RTDs simultaneously.
E|
||||| 10 Contact Inputs, 7 Outputs (2 Form A, 5 Form C)
R
|
|
|
|
|
|
|
|
|
|
|
|
10 Contact Inputs, 4 Outputs (1 Form A, 3 Form C),
3 100 Ohm Platinum RTD Inputs
Current Protection
S
|
|
|
|
|
|
|
|
|
|
Standard configuration: 37, 46, 48, 49, 50P(1), 50G/SG(1),
50N(1), 50L,51R, 66, 86, 51N(1), 51P(1), 50BF
Other Options N | | | | No Selection
M| | | | Voltage, Power, Energy Metering, VTFF (1), 60CTS
P
|
|
|
|
|
|
|
|
Voltage Protection: 37P, 27P(2), 27P_1(2), 47(1), VTFF(1),
59P(2), 81O(2), 81U(2), 59_2(1), 67N(1), 32(2), 60CTS
Communications
S N
|
|
|
|
Standard: Front USB, Rear RS485: Modbus RTU, DNP3.0,
IEC60870-5-103
1 E
|
|
|
|
Standard + Ethernet (Copper + Fiber - MTRJ) Modbus TCP/IP,
DNP3.0, IEC 60870-5-104
2 E
|
|
|
|
Standard + Ethernet (Copper + Fiber - MTRJ) Modbus TCP/IP,
DNP3.0, IEC 60870-5-104, IEC 61850 GOOSE
3 E
|
|
|
|
Standard + Ethernet (Copper + Fiber - MTRJ) Modbus TCP/IP,
DNP3.0, IEC 60870-5-104, IEC 61850
Case Design D | Protection Relay with drawout design
N| Protection Relay with non-drawout design
X| Protection Relay (drawout design) with no chassis
Harsh Environment N None
H Harsh Environment Conformal Coating
