CHAPTER 1: INTRODUCTION 339 ORDER CODES
339 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 1–7
NOTE
NOTE:
The chassis order code and drawout relay order code must match exactly.
FAST PATH:
A drawout relay cannot be used in a chassis with different order code options.
Figure 1-4: 350 chassis order codes
Remote Module I/O
The remote RTD Module provides additional protection.
Other Accessories
• 18L0-0075 3 Series Depth reducing collar - 1.375”
• 18L0-0076 3 Series Depth reducing collar - 3.00”
• 18L0-0080 3 Series IP20 Kit
• 3S-NDO-STCONKIT 3 Series NDO straight terminal block kit
• 0804-0458 USB A-B configuration cable - 6’
NOTE
NOTE:
Refer to the 3 Series Retrofit Instruction Manual for the retrofit of Multilin MI, MII, MLJ, and
TOV relays.
896800CH-A1.fm
339  CH  * * S N * * * *
Phase Currents P1 | | | | | 1 A 3-phase current inputs
P5 | | | | | 5 A 3-phase current inputs
Ground Currents
a
a. Ground current options G1/G5 must match the corresponding P1/P5 Phase currents
G1 | | | | 1 A ground current input
G5 | | | | 5 A ground current input
Other Options N | | | No Selection
M | | | Voltage, Power, Energy Metering, VTFF (1), 60CTS
P
|
|
|
|
|
|
Voltage Protection: 37P, 27P(2), 27P_1(2), 47(1), VTFF(1),
59P(2), 81O(2), 81U(2), 59_2(1), 67N(1), 32(2), 60CTS
Communications
SN
|
|
Standard: Front USB, Rear RS485: Modbus RTU, DNP3.0,
IEC60870-5-103
1E
|
|
Standard + Ethernet (Copper + Fiber - MTRJ) Modbus TCP/IP,
DNP3.0, IEC 60870-5-104
2E
|
|
Standard + Ethernet (Copper + Fiber - MTRJ) Modbus TCP/IP,
DNP3.0, IEC 60870-5-104, IEC 61850 GOOSE
3E
|
|
Standard + Ethernet (Copper + Fiber - MTRJ) Modbus TCP/IP,
DNP3.0, IEC 60870-5-104, IEC 61850
Harsh Environment N None
H Harsh Environment Conformal Coating
896800RMIO-A1.fm
RMIO  * G G * *
Power Supply L | | | | 24 - 48 V DC
H | | | | 110 - 250 V DC / 110 - 230 V AC
I/O Module 1 G | | | Remote Module I/O (3 - 100 Ohm Platinum RTDs)
I/O Module 2 G | | Remote Module I/O (3 - 100 Ohm Platinum RTDs)
I/O Module 3
a
a. RMIO comes standard with 6 RTDs (Modules 1 and 2). The 9 and 12 RTD options (Modules 3 and 4)
require firmware 1.40 or greater.
G| Remote Module I/O (3 - 100 Ohm Platinum RTDs)
X| None
I/O Module 4 G Remote Module I/O (3 - 100 Ohm Platinum RTDs)
X None
