339 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 2–1
339 Motor Protection System
Chapter 2: Installation
GE
Grid Solutions
Instal lation
Mechanical installation
This section describes the mechanical installation of the 339 system, including dimensions
for mounting and information on module withdrawal and insertion.
Dimensions
The dimensions of the 339 are on the following pages. Additional dimensions for mounting
and panel cutouts are shown in the following sections.
