4–12 339 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
A2 METERING CHAPTER 4: ACTUAL VALUES
NEG SEQ VOLTAGE ANGLE
0 V 0
o
lag
Range: 0 to 65535 V
FREQUENCY
0.00 Hz
Range: 40 to 70 Hz
Power
Path: ACTUAL VALUES > A2 METERING > POWER
3 ph REAL POWER
0.0 kW
Range: -100000.0 to 100000.0 kW
3 ph REACTIVE POWER
0.0 kVAR
Range: -100000.0 to 100000.0 kVAR
3 ph APPARENT POWER
0.0 kVA
Range: 0 to 100000.0 kVA
POWER FACTOR
0.00
Range: -0.99 to 1.00
DIRECTIONAL POWER 1
0.00 kW
Range: -100000.0 to 100000.0 kW
DIRECTIONAL POWER 2
0.00 kW
Range: -100000.0 to 100000.0 kW
Energy
NOTE
NOTE:
All negative values (-) represent lead and all positive values (+) represent lag.
Path:
ACTUAL VALUES > A2 METERING > ENERGY
POSITIVE WATTHOUR
0.000 MWh
Range: 0.000 to 50000.000 MWh
NEGATIVE WATTHOUR
0.000 MWh
Range: 0.000 to 50000.000 MWh
POSITIVE VARHOUR
0.000 MVarh
Range: 0.000 to 50000.000 MVarh
NEGATIVE VARHOUR
0.000 MVarh
Range: 0.000 to 50000.000 MVarh
