6–142 339 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
S5 INPUTS/OUTPUTS CHAPTER 6: SETPOINTS
S5 Inputs/Outputs
Figure 6-58: Inputs/Outputs option “E” with BREAKER menu
S5 CONTACT INPUTS
SELECT DC VOLTAGE
52a CONTACT
52b CONTACT
CONTACT INPUT 3
CONTACT INPUT 4
...
CONTACT INPUT 10
▼
S5 INPUTS/OUTPUTS
CONTACT INPUTS
OUTPUT RELAYS
VIRTUAL INPUTS
896768A2.cdr
S5 OUTPUT RELAYS
RLY1 TRIP
RLY2 CLOSE
RLY3 START INHIBIT
RLY4 AUXILIARY
RLY5 AUXILIARY
RLY6 AUXILIARY
▼
S5 VIRTUAL INPUTS
VIRTUAL INPUT 1
VIRTUAL INPUT 2
VIRTUAL INPUT 3
VIRTUAL INPUT 4
...
VIRTUAL INPUT 32
▼
NOTE: When SWITCHING DEVICE is selected as BREAKER:
ST
1 output relay (Seal-In) - TRIP
ND
2 output relay (Seal-In) - CLOSE
RD
3 output relay (Self-Reset) - Start Inhibit
TH TH
4 to 6 output relay (Self-Reset or Latched
- Configurable Auxiliary Relays
