339 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 6–1
339 Motor Protection System
Chapter 6: Setpoints
GE
Grid Solutions
Setpoint s
Setpoints Main Menu
The 339 has a considerable number of programmable setpoints, all of which make the
relay extremely flexible. These setpoints have been grouped into a variety of pages and
subpages as shown below. Each setpoints menu has a section that describes in detail the
setpoints found on that menu.
Figure 6-1: Setpoints main menu
