Chapter 1. Programming Site Data
16 DigitalFlow™ GF868 Programming Manual (1-Channel)
1.9.3 Option Card Alarms
1. Use the and [ and the [F1]-[F4] keys to select the desired slot number.
2. Use the [F1]-[F3] keys to set up alarm relays A, B, or C, respectively.
Note: The set up of alarm A is used as an example. Identical procedures would be used to set up the other alarms.
3. Press [F1] = OFF to disable Alarm A and return to the previous prompt, or press [F2] = HIGH, [F3] = LOW or [F4] =
FAULT to specify the type for Alarm A.
4. Press [F1] = NO for standard operation or [F2] = YES for Failsafe operation.
5. Do one of the following:
• If you selected FAULT, proceed to step 6.
• If you selected HIGH or LOW, complete the steps below.
a. Use the and [ and
[F1]-[F4] keys to specify the desired Output Measurement parameter, as shown in
Figure 12 on page 88.
b. Enter a value for the trigger point of the alarm and press [ENT].
6. To select the Fault Type that will trigger the alarm, press F1 = FLOW, F2 = OTHER (non-flow), or F3 = ALL.
7. Press [F1]-[F3] to set up another alarm or press [EXIT] to select another slot for set up.
For instructions on setting up additional inputs and/or outputs proceed to the appropriate section. Otherwise, press
[EXIT] to return to the main I/O menu prompt.
