DigitalFlow™ GF868 Programming Manual (1-Channel) 65
Chapter 4. Printing Data
4.4 Print Site File
Use the PROG submenu to print the data in a site file that was set up and saved as described in Chapter 1, Programming
Site Data. To print a site file, refer to Figure 15 on page 91 and complete the following steps:
IMPORTANT: Make sure that a printer has been properly set up before proceeding with this section.
1. To access the Print Menu, press the [PRNT] key.
Note: The Print Menu is not protected by the security feature and a password is never required to access this menu.
2. Press [F3] = PROG.
3. Use the [, [ and [F1]-[F4] keys to select the desired Site File to print.
Note: All site files currently in memory appear on the option bar. The active site file is always listed as the first choice
(Work).
The Model GF868 returns to the standard data display screen and generates a site file printout similar to the one shown
in Figure 7. The printout continues until the entire file has been printed or until a STOP command is issued (see the
instructions for the STOP submenu on the next page.
Figure 7: A Typical Site File Printout
Mass Flow Units
Pipe OD
.
Pipe Wall
Path Length
Axial Dimension L
PIPE PARAMETERS:
Transducer number
Mass Decimal Digits
.
Mass Units
CHAN SYSTEM PARAMETERS
Equation
Ch1 Channel LABEL Channel MESSAGE
CHAN ACTIVE PARAMETERS
Site status
Skan/measure mode
Burst
Skan Only
Standard Equation
Thousands ACF
/min
0
Pounds
0
81
12.000 inches
0.200 inches
16.97 inches
12.00 inches
.
.
At 9:54:39 AM on 11 FEB 99
Wit
h 1K FIFO and 1113 receiver board
Model GX868G3G
PROGRAM PARAMETERS of SITE NAME
Mass Flow Time
MDOT Decimal Digits
Volumetric Units
Volumetric Time
VOL Decimal Digits
Totalizer Units
TOT Decimal Digits 0
Actual cubic ft
Pounds
/sec
0
