DigitalFlow™ GF868 Programming Manual (1-Channel) 67
Chapter 4. Printing Data
4.7 Printing Signal Array Data
Use the SGNLS submenu to print signal array data, to help diagnose certain problems. To print the signal data, see
Figure 15 on page 91 and complete the following steps:
IMPORTANT: Make sure that a printer has been properly set up before proceeding with this section.
1. To access the Print Menu, press the [PRNT] key.
Note: The Print Menu is not protected by the security feature and a password is never required to access this menu.
2. Press the [ or [ key to display the option bar shown, and then press [F2] to select the SGNLS submenu.
3. Press the [F1]-[F3] keys to select the desired Signal Array data to print. To abort the procedure, press the [EXIT] key.
Note: The SIGNL option causes the raw signal array data to print, while the CROSS option causes the
cross-correlation data to print. The BOTH option prints both sets of data.
After the desired print selection has been made, the Model GF868 returns to the standard data display screen and
normal measurement taking. The specified signal array data is printed continuously, until it is manually stopped. To
terminate signal array printing, use the STOP submenu, as described earlier in this chapter. A portion of a typical
printout is shown in Figure 8.
Figure 8: A Typical Signal Array Printout
CH1
0
1
2
.
.
.
760
761
762
.
.
.
36
2
34
32
2
SKAN
2
38
0
34
34
0
SIGNAL
0
757
758
759 40
40
41
42
44
45
763 36 36
To Next Page
