User Manual Druck DPI612
Page 60 of 105 [EN] English – 109M4017 Revision -
2.4.2 Set the Function Utility Options
For each function only one utility may be active. Not all source and
measure functions have associated utilities. For all options, the
button resets the additional readings.
a. Max/Min. Avg
This utility is only available with measure functions.
The additional values displayed show the minimum, maximum, and
average values of the input signal.
Figure 2-14 Max/Min Example
b. Switch Test
This utility is available with pressure functions.
The additional values displayed show signal values (measure or
source) when the instrument detects a switch opening and closing.
