GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
4-8 Section 4-3 - General Procedure
4-3-5-2 LOGIQ P3 SoftMenu Key Tour
In general, there are two types of NTPUI/SoftMenu keys: Paddle Switch and adjustable knobs.
1.) The Paddle Switch is used to access and adjust the Sub SoftMenu.
2.) Press the adjustable knobs to toggle option menu between line one and line two.
3.) Rotate the adjustable knobs to adjust the corresponding parameters.
Figure 4-6 SoftMenu Key Tour
