IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
7-24 Section 7-6 - Troubleshooting
7-6-3 LCD Troubleshooting
LCD does not work
- Check if LCD is getting power.
- Check if LCD Video signal cable is connected properly on either end.
Colored stains appear in image
- Check for Video cable of LCD.
- Change LCD setting in system.
- Replace the LCD.
7-6-4 Network Troubleshooting Trees
7-6-4-1 No Connection to the Network at All
1.) Check if the LCD indicates the network connection is working in normal status.
Click Start
button on the bottom left of the status bar, select Network Connections. (refer to 7-69)
a.) Check whether your Wireless Network Connection
or Local Area Connection is installed
successfully. (refer to Figure 7-70)
Figure 7-21 Start menu
Figure 7-22 Network Connection
