IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
10-14 Section 10-7 - Electrical Safety Tests
10-7-2-1 LOGIQ Ultrasound System Leakage Current Limits
Leakage current limits for LOGIQ Ultrasound Systems are shown below for 100-120 Volt and 230-240 Volt mains.
NOTE: Open Grounding is also known as “Lift Ground”.
Table 10-13: Leakage current limits for LOGIQ Ultrasound system operation on 100-
120 Volt mains (US/Canada/Japan)
Leakage Current Test System
Power
Grounding/
PE Conductor
Limit mA
Chassis/Enclosure Leakage On and Off Open 0.3
Type BF and CF Applied Parts On (transmit) Closed
Open
0.01
0.05
Type CF Applied Parts (sink
leakage)
On and Off Closed 0.05
Table 10-14: Leakage current limits for LOGIQ Ultrasound system operation on 230-
240 Volt mains
Leakage Current Test System
Power
Grounding/
PE Conductor
Limit mA
Chassis/Enclosure Leakage On Open and Closed 0.5
Type BF Applied Parts On (transmit) Open 0.1
Type CF Applied Parts On (transmit) Open 0.05
Type CF Applied Parts (sink
leakage)
On and Off Closed 0.05
