GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
Chapter 9 Renewal Parts 9-17
Table 9-8 Power Cable Set
Compatibility
Item Part Name
Part
Number Description
P3 -
R1.x.x
P3
BT10
R2.x.x Qty
901 Cable Assembly 5342775
Cable Assembly: 1 Power entry to PS,
Relay and Printer
No Yes 1
902 PDB to Conn Brd 5342888
PDB to Conn Board, MST Board and
RP2 BRD_Cable Assembly
No Yes 1
903 LCD DC Power cable 5366298 LCD DC Power cable No Yes 1
904 Dual SATA Power Cable 5269919 Dual SATA Power Cable Yes Yes 1
905 PDB to KBD and Fan 5270870 PDB to KBD and Fan Yes Yes 1
906 Conn Brd to TXB 5269067 Connector Board to TX Board Yes Yes 1
907
MST to KBD & DVD SATA Signal
cable
5263844
MST to KBD & DVD SATA Signal
cable
Yes Yes 1
908 Power Supply output to PDB 5342783 Power Supply output to PDB No Yes 1
909 Power Supply Fan Cable Assembly 5390435 Power Supply Fan Cable Assembly No Yes 1
910 Cable assembly: 4 PDB to SBV board 5342782 Cable assembly: 4 PDB to SBV board No Yes 1
911 LCD DC Power cable 5269791 LCD DC Power cable Yes No 1
912 PDB to Conn Brd 5269059 PDB to Conn Board, MST Board Yes No 1
Cable Assembly 5270783
Cable Assembly For Transformer to
PS, SSR and Peripheral Connector
Yes No 1
Cable Assembly
5262720
Cable Assembly for Panel mount con-
nector to power supply & solid state
relay
Yes No 1
Cable Assembly
5262046
Cable Assembly For Peripheral Con-
nector to Rear panel sockets
Yes No 1
Cable Assembly 5263747
Cable Assembly For Docking Brd to
RP2 FRC cable
Yes No 1
Cable Assembly 5342780
Power Assembly to Power supply and
Relay Card_Cable assembly
No Yes 1
To Next Page
