GE LOGIQ P6 Service Manual

GE HEALTHCARE
DIRECTION 5245279, REVISION 3 LOGIQ™ P6/P6 PRO SERVICE MANUAL
Section 7-9 - Trouble Shooting Tree 7 - 35
7-9-7 Monitor Troubleshooting (cont’d)
• Monitor does not display
- Check AC circuit breaker
- Verify power is present at monitor outlet
- Check if video is present at backplane
• Monitor display does not match with print out.
- Verify factory default settings. Chapter 18 in the User Manual calls out suggested settings for
various exam and lighting conditions.
• Video test patterns are not clear, bright, parallel or square
- Replace the monitor
Figure 7-20
Yes
Is the shutdown dialog
box displayed?
Did the scanner
Shut off?
Yes
Press and hold the ON/OFF switch on
the scanner for approximately 5
seconds.
If the scanner fails to Shut Off, follow the
step below.
Check cable connection
If the scanner still does not Shut off,
Switch the circuit breaker to the OFF
position.
NO
NO
Press once the on/off switch.
Shutdown the scanner from a software
screen or depress the ON/OFF switch
Switch the breaker to the
OFF position.to
completely Power Down
the scanner.
Press and hold on/off switch until
system shut down.
