GE HEALTHCARE
DIRECTION 5245279, REVISION 3 LOGIQ™ P6/P6 PRO SERVICE MANUAL
7 - 34 Section 7-9 - Trouble Shooting Tree
7-9-7 Monitor Troubleshooting
NOTE: Reset the monitor settings to the factory defaults prior to troubleshooting the monitor.
NOTICE
Comments to remember about the 17” monitor.
The monitor is the diagnostic monitor and is connected to AC 110/220 VAC.
The monitor powers down with the console.
Power output from AC Power assy via AC distributor in AC Transbox assy:
To Next Page
