GE LOGIQ P6 Service Manual

GE HEALTHCARE
DIRECTION 5245279, REVISION 3 LOGIQ™ P6/P6 PRO SERVICE MANUAL
9 - 10 Section 9-6 - NEST
Section 9-6 NEST (cont’d)
Item Part Name FRU Number Description Qty FRU R1.0.x R2.0.x
401 PI128 II Assy 5327228
Probe Conneciton
Board
11Yes Yes
402 DTRX64II Assy 5252321-2
64Ch TX/RX
Beamforming Board
11Yes Yes
403 CWD64 Assy 5245003
64Ch Continous Wave
Doppler Board
11Yes Yes
404 SYSCONML Assy (with SOM) 5252326-2
Main Control & BEP
Board
11Yes Yes
405 APS II Assy 5245004
DC Voltage Power
Supply
11Yes Yes
406 DualCore SOM 5252327-2 PC module 1 1 Yes Yes
407 RFC Assy 5252324
128Ch TX/RX Signal
Connection Board
11Yes Yes
408 BP128 Assy 5252320 Backplane Board 1 1 Yes Yes
409 P6 Nest FAN Assy 5252349 FAN assy for Nest Box 1 1 Yes Yes
410 P6 TRANS FAN Assy 5252350 FAN assy for TransBox 1 1 Yes Yes
411 DTRX Cooler with heatsink 5252351
FAN cooler in
DTRX64II
21Yes
412 SYSCON Base 5270805-2 1 1 Yes Yes
413 LP6 CW Doppler kit 5269166 1 1 Yes Yes
414 P3RLY assy 5144579-2 LP6 BT09 Pro Only 1 1 Yes
415 RFC PRO Assy 5266433 LP6 BT09 Pro Only 1 1 Yes
Table 9-5 NEST
