GE HEALTHCARE
DIRECTION 5245279, REVISION 3 LOGIQ™ P6/P6 PRO SERVICE MANUAL
8 - 56 Section 8-2 - DISASSEMBLY/RE-ASSEMBLY
8-2-21 Neck Front
8-2-21-1 Tools
• Common philips screwdrivers
8-2-21-2 Preparations
• Shut down the system and switch off the main breaker.
8-2-21-3 Removal procedure
1.) Remove 1 rubber cap. Refer to the figure below.
2.) Unscrew 1 screw and remove the Neck Front. Refer to the figure below.
Figure 8-96 rubber cap of neck front cover
Figure 8-97 Open neck front cover
To Next Page
