GE LOGIQ P6 Service Manual

GE HEALTHCARE
DIRECTION 5245279, REVISION 3 LOGIQ™ P6/P6 PRO SEVICE MANUAL
1-6 Section 1-2 - Important Conventions
"OFF/Standby" Indicates the power off/
standby position of the power switch.
CAUTION
This Power Switch DOES NOT ISOLATE
Mains Supply
Adjacent to On-Off/Standby Switch
"Mains ON" Indicates the power on position of
the mains power switch.
"ON" Indicates the power on position of the
power switch.
CAUTION
This Power Switch DOES NOT ISOLATE
Mains Supply
Front Panel Switch
"Protective Earth" Indicates the protective
earth (grounding) terminal.
Internal
Indicates an earth GROUND potential
Product schematics
Peripherals
Table 1-5 Product Icons
LABEL/SYMBOL PURPOSE/MEANING LOCATION

GE LOGIQ P6 Specifications

General

Type	Ultrasound System
Connectivity	DICOM, USB, Ethernet
Applications	Obstetrics, Gynecology, Vascular, Cardiology, Musculoskeletal
Probes	Convex, Linear, Phased Array
Imaging Modes	B-mode, M-Mode, Color Doppler, Power Doppler, Pulsed Wave Doppler
Portability	Mobile
Transducer Ports	3 active ports
