GE HEALTHCARE
DIRECTION 5245279, REVISION 3 LOGIQ™ P6/P6 PRO SERVICE MANUAL
3-8 Section 3-1 - Overview
Section 3-3 Receiving and Unpacking the Equipment (cont’d)
6.) Remove the MONITOR SUPPORTER and Option Box.
7.) Remove the PLASTIC BAG.
8.) Unlock the front caster and carefully put the console off the PALETTE.
Figure 3-6 Moving the LOGIQ™ P6/P6 Pro from the crate
Monitor Pad
To Next Page
