Replacement Procedures
7-34 LOGIQ V2/LOGIQ V1 – Basic Service Manual
5610739-100 English Rev.10
Windows License Label
After upgrading from R1.0.x to R1.1.x, Windows License Label
needs to be attached to the bottom of the system to replace the
original one.
NOTE: The Windows License Label to replace the original one is only
required for upgrade from R1.0.x to R1.1.x.
1. Take out the windows license label, pell off the yellow part of
the paster.
Figure 7-22. Windows license label
2. Make sure the backcover is clean and dry. Then align the
paster and attach it in the location illustrated by the figure.
Figure 7-23. Windows license label location
• 1: Windows License Label
