GEK-106237P MIFII Digital Feeder Relay 5-9
5 SETTINGS 5.3 ADVANCED SETTINGS
5
5.3.3 THERMAL IMAGE SETTINGS (49) (GROUP 2)
USER CURVE
ENERVISTA MII SETUP HMI DEFAULT RANGE STEP
Thermal Image group 2 49 Function (group 2) THERMAL MODEL 49
Permission to Trip Trip Enable 49 Trip Enable 49 No Yes/No NA
49 Pickup Pickup 49 Pickup 49 1 In (Phase) 0.10 – 2.40 In (Ph) 0.01 In (Ph)
Overload Percent Alarm Alarm Level 49 Alarm Level 49 80 % 70% – 100% ITH
Heating Time Constant τ1 Heat Time 49 Heat Time 49 6 3 – 600 min. 1 min.
Cooling Time Constant τ2 Cool Time 49 Cool Time 49 1 1– 6 times τ11
ENERVISTA MII SETUP HMI DEFAULT RANGE STEP
Parameters User Curve User Curve
A A Parameter A Parameter 0.0500 0.0000-125.0000 0.0001
B B Parameter B Parameter 0.0000 0.0000-3.0000 0.0001
P P Parameter P Parameter 0.0400 0.0000-3.0000 0.0001
Q Q Parameter Q Parameter 1.0000 0.0000-2.0000 0.0001
K K Parameter K Parameter 0.000 0.000-1.999 0.001
