GEK-106237P MIFII Digital Feeder Relay 8-1
8 KEYPAD AND DISPLAY 8.1 DESCRIPTION
8
8 KEYPAD AND DISPLAY 8.1DESCRIPTION
MIFII has five types of display messages: actual values, main settings, advanced settings, operations and date & time.
Actual values are values that are measured by the relay, such as currents; digital values of the relay, and can be digital
inputs, outputs status and others; or internal information as the firmware revision. Main settings and advanced settings
comprise product setup, communications and protection elements adjustments. Operations are the available commands
that can be performed in the relay.
These types of messages are located within a menu structure that groups the information into categories. This chapter
describes the way to navigate this menu structure and shows the complete structure so that the user can reach certain
screens quickly.
