GEK-106237P MIFII Digital Feeder Relay 6-5
6 I/0 CONFIGURATION 6.2 OUTPUTS AND LEDS CONFIGURATION (FOR OPTIONS 1 AND 2)
6
6.2OUTPUTS AND LEDS CONFIGURATION (FOR OPTIONS 1 AND 2) 6.2.1 DESCRIPTION OF OUTPUTS AND LEDS
MIFII incorporates 6 outputs and 6 LED indicators. 4 of the outputs and LED indicators are user configurable, and can only
be programmed using EnerVista MII SETUP software (SETPOINT – RELAY CONFIGURATION). The first two LEDs are
fixed for READY (System ready) and TRIP. The fixed outputs are programmed for ALARM (System alarm) and TRIP.
The TRIP LED activates when the TRIP contact closes.
The READY LED turns on when all the following conditions are fulfilled:
• The relay status is READY
• At least one of the protection functions of the active table is enabled
• The trip of at least one of the enabled functions is also enabled.
The default configuration for outputs is as follows:
The default LED configuration is as follows:
OUTPUT CONFIGURATION MEMORY
MODELS WITHOUT
RECLOSER
MODELS WITH RECLOSER
1 Phase trip Close breaker No
2 Ground trip Phase trip No
3 50 trip Ground trip No
4 49 Alarm 50 trip No
LED CONFIGURATION MEMORY
1 Phase trip Yes
2 Ground trip Yes
350 Trip Yes
4Pickup No
