2-16 MIFII Digital Feeder Relay GEK-106237P

2.10 EVENTS (AVAILABLE IN OPTION 1 AND OPTION 2 MODELS) 2 PRODUCT DESCRIPTION

2.10 EVENTS (AVAILABLE IN OPTION 1 AND OPTION 2 MODELS)

MIFII stores an historical record with the last 32 events. Each event contains the event description, date and time (4 ms

accuracy), the current values in phases and ground at that moment, and a summary of the status signals that can produce

events, and whether they were active or not in that moment.

In EnerVista MII SETUP there is an “EVENTS” menu, where the user can check how many events have been produced

since the last time the Events were deleted. If the number of events produced is higher than 32 (maximum number of

events stored), this means that only the last 32 will be stored.

This event record is stored in a capacitor backed up RAM memory. Events functionality in MIFII is performed via the

EnerVista MII SETUP software.

Inside the ADVANCED SETTINGS group, there is a sub-group called EVENT MASKS, from where the different causes that

can produce events can be masked. They are detailed in the SETPOINT – SETPOINT – ADVANCED SETTINGS – EVENT

MASK section. The following table shows a list of all possible events.

MIFII relay with option C stores an historical record with the last 100 events. Each register contains the event description,

date and time (4ms accuracy), the current values in phases and ground at that moment and a summary of the status

signals tha can produce events and whether they were active or not in that moment.

Table 2–1: LIST OF EVENTS

DESCRIPTION OPTION 1 OPTION 2

50P1 Pickup/Drop out Yes

50P2 Pickup/Drop out Yes

50G1 Pickup/Drop out Yes

50G2 Pickup/Drop out Yes

51P Pickup/Drop out Yes

51G Pickup/Drop out Yes

49 Alarm Pickup/Drop out Yes

50P1 Trip Yes

50P2 Trip Yes

50G1 Trip Yes

50G2 Trip Yes

51P Trip Yes

51G Trip Yes

49 Trip Yes

General trip Yes

50P1 Trip enable/disable by digital input Yes Yes

50P2 Trip enable/disable by digital input Yes Yes

50G1 Trip enable/disable by digital input Yes Yes

50G2 Trip enable/disable by digital input Yes Yes

51P Trip enable/disable by digital input Yes Yes

51G Trip enable/disable by digital input Yes Yes

49 Trip enable/disable by digital input Yes Yes

General trip enable/disable by digital input Yes Yes

Protection status in service/out of service Yes Yes

Digital output 1 active/non active Yes Yes

Digital output 2 active/non active Yes Yes

Digital output 3 active/non active Yes Yes

Digital output 4 active/non active Yes Yes

Digital input 1 active/non active Yes Yes

Digital input 2 active/non active Yes Yes

Settings change disabled by digital input active/non active Yes Yes

Trip operation by digital input Yes Yes

Trip operation by command Yes Yes

Auxiliary digital output latch reset Yes Yes
