5.2MAIN SETTINGS 5.2.1 GENERAL SETTINGS
*Only available for option C models. For further information please see APPENDIX E
ENERVISTA MII SETUP HMI DEFAULT RANGE STEP
PRODUCT SETUP PRODUCT SETUP PRODUCT SETUP
Relay Status Relay Operation Relay Operation DISABLE READY / DISABLE NA
Frequency Frequency Frequency 60 Hz 50/60 Hz NA
ModBus Format --- ModBus Format Intel Intel/Motorola NA
Phase CT ratio Phase CT Ratio Phase CT Ratio 1 1-4000 1
Ground CT ratio Ground CT Ratio Ground CT Ratio 1 1-4000 1
HMI Password --- HMI Password 0 0-9999 1
Comm Password --- Comm Password 1 1 – 255 1
Slave Address --- Slave Address 1 1 – 255 1
Communication Baud rate --- Comm Baud Rate 9.6 0.3, 0.6, 1.2, 2.4, 4.8,
9.6, 19.2
NA
Communication 2 Baud
rate*
--- COM2 Baud rate 9.6 0.3,0.6,1.2,2.4,4.8,9.
6,19.2
NA
Prefault cycles* Prefault Cycles Prefault Cycles 50 10-140 1
