2-28 MIFII Digital Feeder Relay GEK-106237P
2.16 TECHNICAL SPECIFICATIONS 2 PRODUCT DESCRIPTION
2
Max. Ratings for 100.000 operations:
2.16.6 COMMUNICATIONS
2.16.7 ENVIRONMENTAL
2.16.8 TYPE TESTS AND CERTIFICATIONS
The MIFII system complies with the following standards, which include the standards required by Community Directive 89/
336 for the CE marking, in line with European standards. It also complies with the European directive requirements for low
voltage, and the environmental and operating requirements established in ANSI standards C37.90, IEC 255-5, IEC 255-6
and IEC 68.PRODUCTION TESTS
VOLTAGE
MAKE&CARRY
CONTINUOUS
MAKE&CARRY 0.2 SEC BREAK MAX LOAD
DC Resistive
24 Vdc 10 A 48 A 10 A 384W
48 Vdc 10 A 48 A 2.6 A 125W
125 Vdc 10 A 48 A 0.6 A 75 W
250 Vdc 10 A 48 A 0.5 A 125 W
AC Resistive
120 Vac 10 A 48 A 10 A 1920 VA
250 Vac 10 A 48 A 10 A 4000 VA
AC Inductive PF = 0.4
250 Vac 10 A 30 A 10 A 1000 VA
FRONT PORT RS232 300, 600, 1200, 2400, 4800, 9600 or 19200 bps,
Modbus® RTU
REAR PORT RS485 300, 600, 1200, 2400, 4800, 9600 or 19200 bps,
Modbus® RTU
9600 or 19200
IEC60870-5-103
Operating Temperatures: -20º C to +60º C
Ambient Storage Temperatures: -40º C to +80º C
Maximum relative humidity 95%
Altitude 2000 m. Max
Pollution Degree 2
STANDARD DESCRIPTION CLASS
ELECTROSTATIC COMPATIBILITY AND INSULATION
IEC 60255-25 / EN 61000-6-4 (2001) Conducted and Radiated Emission
ENV 50204 (1995) Radiated Electromagnetic Fields with
Frequency Modulation
10 V/m, 900 MHz
IEC 60255-22-2 / EN 61000-6-2 (2001) Electrostatic Discharge Immunity Test Level 4 CM (8 kV). Level 3 AM (8 kV)
IEC 60255-22-3 / EN 61000-6-2 (2001) /
ENV 50204 (1995)
Radiated RF Fields Immunity Test Level 3 (10 V/m), 80-1000 MHz.
